Zipato
Siren alarm EU
SKU: ne-nas-ab02z.eu
Quickstart
This is a
The indoor siren can be included to the Z-Wave network by pressing the code button.1) Disassemble the siren and insert the battery intothe siren. Make sure the device is located withinthe direct range of the controller.2) Set the controller into the inclusion mode (seemain controllers operating manual).3) Quickly triple click the code button, LED light willflash red for 5 times.4) The Indoor siren will be detected and includedin the Z-Wave network.5) Wait for the main controller to configure the siren.SMART START. This product also supports Z-Wave Smart Start option which enables easier inclusion. QR code for SmartStart inclusion is printed on the battery cover. SmartStart option is only possible when network controller is also supporting SmartStart.
Important safety information
Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law. The manufacturer, importer, distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material. Use this equipment only for its intended purpose. Follow the disposal instructions. Do not dispose of electronic equipment or batteries in a fire or near open heat sources.What is Z-Wave?
Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section.
Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is not in direct wireless range of the transmitter.
This device and every other certified Z-Wave device can be used together with any other certified Z-Wave device regardless of brand and origin as long as both are suited for the same frequency range.
If a device supports secure communication it will communicate with other devices secure as long as this device provides the same or a higher level of security. Otherwise it will automatically turn into a lower level of security to maintain backward compatibility.
For more information about Z-Wave technology, devices, white papers etc. please refer to www.z-wave.info.
Product Description
Alerts you if an intruder tries to get into your home through your doors or windows. Set the siren and warning light to turn on when unexpected activity is detected. Set up the siren so that its triggered automatically by your sensors and camera.Get smart alerts when doors or windows are opened unexpectedly or when motion is detected.
Prepare for Installation / Reset
Please read the user manual before installing the product.
In order to include (add) a Z-Wave device to a network it must be in factory default state. Please make sure to reset the device into factory default. You can do this by performing an Exclusion operation as described below in the manual. Every Z-Wave controller is able to perform this operation however it is recommended to use the primary controller of the previous network to make sure the very device is excluded properly from this network.
Reset to factory default
This device also allows to be reset without any involvement of a Z-Wave controller. This procedure should only be used when the primary controller is inoperable.
Reset procedure will remove all information on the Z-Wave network or Z-Wave controller and restore the sensor to factory default settings. Please use this procedure only when the network primary controller is missing or otherwise inoperable.1) Remove the sensors cover2) Make sure the sensor is connected to power source 3) Press the code button for 10 seconds, LED will flash blue for 3 seconds4) Release the code buttonNote: When the siren is being restored to factory settings, please make sure power source is connected.
Inclusion/Exclusion
On factory default the device does not belong to any Z-Wave network. The device needs to be added to an existing wireless network to communicate with the devices of this network. This process is called Inclusion.
Devices can also be removed from a network. This process is called Exclusion. Both processes are initiated by the primary controller of the Z-Wave network. This controller is turned into exclusion respective inclusion mode. Inclusion and Exclusion is then performed doing a special manual action right on the device.
Inclusion
The indoor siren can be included to the Z-Wave network by pressing the code button.1) Disassemble the siren and insert the battery intothe siren. Make sure the device is located withinthe direct range of the controller.2) Set the controller into the inclusion mode (seemain controllers operating manual).3) Quickly triple click the code button, LED light willflash red for 5 times.4) The Indoor siren will be detected and includedin the Z-Wave network.5) Wait for the main controller to configure the siren.SMART START. This product also supports Z-Wave Smart Start option which enables easier inclusion. QR code for SmartStart inclusion is printed on the battery cover. SmartStart option is only possible when network controller is also supporting SmartStart.Exclusion
1) Make sure the siren is connected to power source. 2) Set the main controller into the exclusion mode(see main controllers operating manual).3) Quickly triple click the code button, LED lightwill flash red for 5 times4) Wait for the main controller to remove the sensor.Quick trouble shooting
Here are a few hints for network installation if things dont work as expected.
- Make sure a device is in factory reset state before including. In doubt exclude before include.
- If inclusion still fails, check if both devices use the same frequency.
- Remove all dead devices from associations. Otherwise you will see severe delays.
- Never use sleeping battery devices without a central controller.
- Dont poll FLIRS devices.
- Make sure to have enough mains powered device to benefit from the meshing
Association - one device controls an other device
Z-Wave devices control other Z-Wave devices. The relationship between one device controlling another device is called association. In order to control a different device, the controlling device needs to maintain a list of devices that will receive controlling commands. These lists are called association groups and they are always related to certain events (e.g. button pressed, sensor triggers, ...). In case the event happens all devices stored in the respective association group will receive the same wireless command wireless command, typically a 'Basic Set' Command.
Association Groups:
| Group Number | Maximum Nodes | Description |
|---|---|---|
| 1 | 5 | Z-Wave Plus Lifeline, reports relays status to just one device, Z-wave networks main controller by default. Its not recommended to modify settings of this association group. |
| 2 | 5 | is assigned to the siren status - ON/OFF. Allows for sending a controlled command to the associated device whenever the Indoor siren is turned ON (or OFF). |
Configuration Parameters
Z-Wave products are supposed to work out of the box after inclusion, however certain configuration can adapt the function better to user needs or unlock further enhanced features.
IMPORTANT: Controllers may only allow configuring signed values. In order to set values in the range 128 ... 255 the value sent in the application shall be the desired value minus 256. For example: To set a parameter to 200 it may be needed to set a value of 200 minus 256 = minus 56. In case of a two byte value the same logic applies: Values greater than 32768 may needed to be given as negative values too.
Parameter 1: Configure alarm volume
This parameter defines the output volume when siren plays alarm. Doorbell alarm volume has three settings, Low (Parameter is set to 1), Middle (Parameter is set to 2), High (Parameter is set to 3). The default value is 2. Size: 1 Byte, Default Value: 2
| Setting | Description |
|---|---|
| 1 - 3 | Low, Middle, High |
Parameter 2: Configure alarm duration time
This Parameter defines the alarm duration time when siren receives an alarm sensor notification report or an alarm command from controller. Siren duration time has three settings: 30 seconds (Parameter is set to 1), 1 minute (Parameter is set to 2), 5 minute (Parameter is set to 3). The default value is 2. Size: 1 Byte, Default Value: 2
| Setting | Description |
|---|---|
| 1 - 3 | 30 sec, 1 min, 5 min |
Parameter 3: Configuring doorbell music duration time
This parameter defines the doorbell music duration time when siren receives a door/window sensor notification report or an alarm command (BASIC_SET =0x02) from a controller. The doorbell music will be played always if this parameter is set to 0. The doorbell music will not be played if this parameter is set to -1. Other values are the doorbell music playing duration time. Unit: Time. Size: 1 Byte, Default Value: 1
| Setting | Description |
|---|---|
| 0 - 127 | Duration |
Parameter 4: Configure doorbell music volume
This parameter defines the output volume when siren plays doorbell music. Doorbell music volume has three settings: Low (Parameter is set to 1), Middle (Parameter is set to 2), High (Parameter is set to3). The default value is 2. Size: 1 Byte, Default Value: 2
| Setting | Description |
|---|---|
| 1 - 3 | Low, Middle, High |
Parameter 5: Configure alarm sound index
This parameter defines the alarm sound index so siren can play different sound when an alarm occurs. There are 10 different sounds for user selection. Size: 1 Byte, Default Value: 9
| Setting | Description |
|---|---|
| 1 - 10 | Sound types |
Parameter 6: Configure doorbell music index
This parameter defines the doorbell music index so siren can play different music when an alarm occurs. There are 10 different music compositions for user selection. Size: 1 Byte, Default Value: 10
| Setting | Description |
|---|---|
| 1 - 10 | Sound types |
Technical Data
| Hardware Platform | ZM5202 |
| Device Type | Siren |
| Network Operation | Listening Sleeping Slave |
| Firmware Version | HW: 96 FW: 2.17 |
| Z-Wave Version | 6.81.01 |
| Certification ID | ZC10-18096228 |
| Z-Wave Product Id | 0x0131.0x0003.0x1083 |
| Supported Notification Types | Siren |
| Security V2 | S2_UNAUTHENTICATED |
| Frequency | XXfrequency |
| Maximum transmission power | XXantenna |
Supported Command Classes
- Association Grp Info
- Association V2
- Basic V2
- Battery
- Configuration
- Device Reset Locally
- Indicator
- Manufacturer Specific V2
- Multi Channel Association V3
- Notification V8
- Powerlevel
- Security 2
- Supervision
- Switch Binary
- Transport Service V2
- Version V3
- Zwaveplus Info V2
Explanation of Z-Wave specific terms
- Controller — is a Z-Wave device with capabilities to manage the network. Controllers are typically Gateways,Remote Controls or battery operated wall controllers.
- Slave — is a Z-Wave device without capabilities to manage the network. Slaves can be sensors, actuators and even remote controls.
- Primary Controller — is the central organizer of the network. It must be a controller. There can be only one primary controller in a Z-Wave network.
- Inclusion — is the process of adding new Z-Wave devices into a network.
- Exclusion — is the process of removing Z-Wave devices from the network.
- Association — is a control relationship between a controlling device and a controlled device.
- Wakeup Notification — is a special wireless message issued by a Z-Wave device to announces that is able to communicate.
- Node Information Frame — is a special wireless message issued by a Z-Wave device to announce its capabilities and functions.
