COQON
Smart Power Adaptor Zwischenstecker
SKU: PSMZ0002
Quickstart
This is a
First start the COQON App. Select "Device" then "Settings" and tap on "+" to add yo ur Smart Plug. Select "Add new COQON Device" then scan the data code of the device or type in the product code manually and press Enter.Now follow the steps in the app and press "inclusion". After the 30 seconds countdown has started press the function key 3 times within 2 seconds to add the Device. Once connected, the Smart Plug LED will stop flashing.
Important safety information
Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law. The manufacturer, importer, distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material. Use this equipment only for its intended purpose. Follow the disposal instructions. Do not dispose of electronic equipment or batteries in a fire or near open heat sources.What is Z-Wave?
Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section.
Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is not in direct wireless range of the transmitter.
This device and every other certified Z-Wave device can be used together with any other certified Z-Wave device regardless of brand and origin as long as both are suited for the same frequency range.
If a device supports secure communication it will communicate with other devices secure as long as this device provides the same or a higher level of security. Otherwise it will automatically turn into a lower level of security to maintain backward compatibility.
For more information about Z-Wave technology, devices, white papers etc. please refer to www.z-wave.info.
Product Description
The adaptor allows the remote controlled switching on and off of the connected electrical devices.It also measures current power consumption and total cumulative consumption.Increase your comfort:Wake up in the morning from the radio, the light goes on and the coffee machine is already preheated.Save energy costs:Disconnect power to your devices at the touch of a button or at a time you specify. - Save energy and costs.
Prepare for Installation / Reset
Please read the user manual before installing the product.
In order to include (add) a Z-Wave device to a network it must be in factory default state. Please make sure to reset the device into factory default. You can do this by performing an Exclusion operation as described below in the manual. Every Z-Wave controller is able to perform this operation however it is recommended to use the primary controller of the previous network to make sure the very device is excluded properly from this network.
Reset to factory default
This device also allows to be reset without any involvement of a Z-Wave controller. This procedure should only be used when the primary controller is inoperable.
To set the device back to factory default press the function key for 10 seconds. The LED will flash red 5 times and then turn off. Please use this procedure only when the primary controller is missing or inoperable.
Safety Warning for Mains Powered Devices
ATTENTION: only authorized technicians under consideration of the country-specific installation guidelines/norms may do works with mains power. Prior to the assembly of the product, the voltage network has to be switched off and ensured against re-switching.
Inclusion/Exclusion
On factory default the device does not belong to any Z-Wave network. The device needs to be added to an existing wireless network to communicate with the devices of this network. This process is called Inclusion.
Devices can also be removed from a network. This process is called Exclusion. Both processes are initiated by the primary controller of the Z-Wave network. This controller is turned into exclusion respective inclusion mode. Inclusion and Exclusion is then performed doing a special manual action right on the device.
Inclusion
First start the COQON App. Select "Device" then "Settings" and tap on "+" to add yo ur Smart Plug. Select "Add new COQON Device" then scan the data code of the device or type in the product code manually and press Enter.Now follow the steps in the app and press "inclusion". After the 30 seconds countdown has started press the function key 3 times within 2 seconds to add the Device. Once connected, the Smart Plug LED will stop flashing.Exclusion
First start the COQON App. Select the device you want to remove and tap on the trash can icon to start the "exclusion" process , then press "exclude now". After the 30 seconds countdown has started press the function key 3 times within 2 seconds to remove the Device.Quick trouble shooting
Here are a few hints for network installation if things dont work as expected.
- Make sure a device is in factory reset state before including. In doubt exclude before include.
- If inclusion still fails, check if both devices use the same frequency.
- Remove all dead devices from associations. Otherwise you will see severe delays.
- Never use sleeping battery devices without a central controller.
- Dont poll FLIRS devices.
- Make sure to have enough mains powered device to benefit from the meshing
Association - one device controls an other device
Z-Wave devices control other Z-Wave devices. The relationship between one device controlling another device is called association. In order to control a different device, the controlling device needs to maintain a list of devices that will receive controlling commands. These lists are called association groups and they are always related to certain events (e.g. button pressed, sensor triggers, ...). In case the event happens all devices stored in the respective association group will receive the same wireless command wireless command, typically a 'Basic Set' Command.
Association Groups:
| Group Number | Maximum Nodes | Description |
|---|---|---|
| 1 | 5 | Z-Wave Plus Lifeline |
| 2 | 5 | Follow State |
| 3 | 5 | Follow Complementary State |
| 4 | 5 | Metering - High Threshold - Set On/Off |
| 5 | 5 | Metering - Low Threshold - Set On/Off |
Configuration Parameters
Z-Wave products are supposed to work out of the box after inclusion, however certain configuration can adapt the function better to user needs or unlock further enhanced features.
IMPORTANT: Controllers may only allow configuring signed values. In order to set values in the range 128 ... 255 the value sent in the application shall be the desired value minus 256. For example: To set a parameter to 200 it may be needed to set a value of 200 minus 256 = minus 56. In case of a two byte value the same logic applies: Values greater than 32768 may needed to be given as negative values too.
Parameter 1: Power Status
Status when power is powered up Size: 1 Byte, Default Value: 2
| Setting | Description |
|---|---|
| 0 | 0= OFF |
| 1 | 1= ON |
| 2 | 2= Status when last powered |
Parameter 21: Power Changes Report
Power Changes Sending Report Size: 1 Byte, Default Value: 10
| Setting | Description |
|---|---|
| 0 | 0= Power Sending Report disable |
| 1 - 100 | 1-100 = Power changes (%W) when report will be sent |
Parameter 22: Overload Power Report
Overload Power Report Size: 2 Byte, Default Value: 3000
| Setting | Description |
|---|---|
| 0 | 0= Overload Report disable |
| 1 - 3680 | 1-3680 = 1-3680W |
Parameter 23: Energy Report
Energy Sending Report Size: 2 Byte, Default Value: 1000
| Setting | Description |
|---|---|
| 0 | 0= Energy Report disable |
| 1 - 32767 | 1-32767= 1Wh to 32767 Wh |
Parameter 24: Meterin Report
Metering Report Time (second) Size: 2 Byte, Default Value: 3600
| Setting | Description |
|---|---|
| 0 | 0= Metering Report disable |
| 1 - 32767 | 30-32767= Metering Report sent to lifeline |
Parameter 25: High Power Treshold
High Power Treshold (W) Size: 2 Byte, Default Value: 3000
| Setting | Description |
|---|---|
| 0 | 0= High Power Threshold disabled |
| 1 - 32767 | 1-32767= High Power Threshold |
Parameter 26: Low Power Threshold
Low Power Threshold (W) Size: 2 Byte, Default Value: 5
| Setting | Description |
|---|---|
| 0 | Low Power Threshold disabled |
| 1 - 32767 | 1-32767= Low Power Threshold |
Parameter 27: Power Threshold Action
Power Threshold Action Size: 1 Byte, Default Value: 12
| Setting | Description |
|---|---|
| 1 | Power Threshold Action disabled |
| 2 | Power High Threshold is enabled and send OFF to group 4 |
| 4 | Power High Threshold is enabled and send ON to group 4 |
| 8 | Power Low Threshold is enabled and send OFf to group 5 |
| 16 | Power Low Threshold is enabled and send ON to group 5 |
Parameter 3: Enable/disable Group 2 & 3
This allows enable/disable for Group 2&3 Size: 1 Byte, Default Value: 3
| Setting | Description |
|---|---|
| 0 | 0= Group 2 & 3 disable |
| 1 | 1= Group 2 enable |
| 2 | 2= Group 3 enable |
| 3 | 3= Group 2&3 enable |
Parameter 5: Over Voltage Alarm
Over Voltage Alarm (V) Size: 2 Byte, Default Value: 0
| Setting | Description |
|---|---|
| 0 | 0= Over Voltage Alarm disabled |
| 1 - 260 | 1-260= Over Voltage Alarm Threshold |
Parameter 6: Over Current Alarm
Over Current Alarm (mA) Size: 2 Byte, Default Value: 0
| Setting | Description |
|---|---|
| 0 | 0= Over Current Alarm disabled |
| 1 - 20000 | 1-20000= Over Current Alaram Threshold |
Technical Data
| Hardware Platform | ZM5101 |
| Device Type | On/Off Power Switch |
| Network Operation | Always On Slave |
| Firmware Version | HW: 0 FW: 1.04 |
| Z-Wave Version | 6.71.01 |
| Certification ID | ZC10-18086200 |
| Z-Wave Product Id | 0x0140.0x0802.0x1002 |
| Supported Meter Type | Electric Energy |
| Color | White |
| Supported Notification Types | Power Management |
| Firmware Updatable | Updatable by Consumer by RF |
| Electric Load Type | Incandescent |
| Security V2 | S2_UNAUTHENTICATED |
| Frequency | XXfrequency |
| Maximum transmission power | XXantenna |
Supported Command Classes
- Association Grp Info V3
- Association V2
- Basic V2
- Configuration
- Device Reset Locally
- Firmware Update Md V4
- Manufacturer Specific V2
- Meter V4
- Multi Channel Association V3
- Notification V8
- Powerlevel
- Protection V2
- Security 2
- Supervision
- Switch All
- Switch Binary
- Transport Service V2
- Version V2
- Zwaveplus Info V2
Controlled Command Classes
- Basic V2
Explanation of Z-Wave specific terms
- Controller — is a Z-Wave device with capabilities to manage the network. Controllers are typically Gateways,Remote Controls or battery operated wall controllers.
- Slave — is a Z-Wave device without capabilities to manage the network. Slaves can be sensors, actuators and even remote controls.
- Primary Controller — is the central organizer of the network. It must be a controller. There can be only one primary controller in a Z-Wave network.
- Inclusion — is the process of adding new Z-Wave devices into a network.
- Exclusion — is the process of removing Z-Wave devices from the network.
- Association — is a control relationship between a controlling device and a controlled device.
- Wakeup Notification — is a special wireless message issued by a Z-Wave device to announces that is able to communicate.
- Node Information Frame — is a special wireless message issued by a Z-Wave device to announce its capabilities and functions.
