HomeSeer

Z-Wave RGB Fan Controller

SKU: HS-FC200+

ZWave+ Security V2

Quickstart

This is a secure Fan Switch for U.S. / Canada / Mexico. To run this device please connect it to your mains power supply. To add this device to your network execute the following action:
Inclusion: Add the device into your network by a Z-Wave certified controller. HS-FC200+ supports the latest S2 security offered by Z-Wave certified controllers. If your controller supports S2, please refer to the user guide of the controller for detailed instructions on adding devices to the network. You should be able to add HS-FC200+ into your network using the unique QR code or the DSK 5 digit pin located on the product or packaging. In addition, the device can be added or removed using the following 2-step procedure:1. Put your Z-Wave controller into Inclusion mode. Consult your controller manual if you're unsure how to do this.2. Tap the paddle of your new HomeSeer switch to begin the inclusion process. This will take a few moments to complete.

Attention: This manual is automatically generated from Z-Wave Alliance Product data and may be incomplete. Please refer to the Manufacturers Manual for more information.


Important safety information

Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law. The manufacturer, importer, distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material. Use this equipment only for its intended purpose. Follow the disposal instructions. Do not dispose of electronic equipment or batteries in a fire or near open heat sources.

What is Z-Wave?

Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section.

Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is not in direct wireless range of the transmitter.

This device and every other certified Z-Wave device can be used together with any other certified Z-Wave device regardless of brand and origin as long as both are suited for the same frequency range.

If a device supports secure communication it will communicate with other devices secure as long as this device provides the same or a higher level of security. Otherwise it will automatically turn into a lower level of security to maintain backward compatibility.

For more information about Z-Wave technology, devices, white papers etc. please refer to www.z-wave.info.

Product Description

HS-FC200+ is a Z-Wave controllable wired fan controller for use with 3-speed or 4-speed ceiling fans. It has a vertical row of LEDs that indicate the fan speed level. Works with 3-speed or 4-speed fans only 4 segment LED dim level indicator Remotely or manually turns ON or OFF, or fan speed level Fits standard wall plates (wall plate not included) Works with any certified gateway supporting Z-Wave

Prepare for Installation / Reset

Please read the user manual before installing the product.

In order to include (add) a Z-Wave device to a network it must be in factory default state. Please make sure to reset the device into factory default. You can do this by performing an Exclusion operation as described below in the manual. Every Z-Wave controller is able to perform this operation however it is recommended to use the primary controller of the previous network to make sure the very device is excluded properly from this network.

Reset to factory default

This device also allows to be reset without any involvement of a Z-Wave controller. This procedure should only be used when the primary controller is inoperable.

To be used only in the event that the network primary controller is lost or otherwise inoperable. (1) Turn switch on by tapping the top of the paddle once. (2) Quickly ap top of the paddle 3 times. (3) Quickly tap bottom of paddle 3 times. (4) If the LED turns off then on again, switch is reset. If not, repeat manual rest.

Safety Warning for Mains Powered Devices

ATTENTION: only authorized technicians under consideration of the country-specific installation guidelines/norms may do works with mains power. Prior to the assembly of the product, the voltage network has to be switched off and ensured against re-switching.

Inclusion/Exclusion

On factory default the device does not belong to any Z-Wave network. The device needs to be added to an existing wireless network to communicate with the devices of this network. This process is called Inclusion.

Devices can also be removed from a network. This process is called Exclusion. Both processes are initiated by the primary controller of the Z-Wave network. This controller is turned into exclusion respective inclusion mode. Inclusion and Exclusion is then performed doing a special manual action right on the device.

Inclusion

Inclusion: Add the device into your network by a Z-Wave certified controller. HS-FC200+ supports the latest S2 security offered by Z-Wave certified controllers. If your controller supports S2, please refer to the user guide of the controller for detailed instructions on adding devices to the network. You should be able to add HS-FC200+ into your network using the unique QR code or the DSK 5 digit pin located on the product or packaging. In addition, the device can be added or removed using the following 2-step procedure:1. Put your Z-Wave controller into Inclusion mode. Consult your controller manual if you're unsure how to do this.2. Tap the paddle of your new HomeSeer switch to begin the inclusion process. This will take a few moments to complete.

Exclusion

Exclusion: Remove the device from your network by a Z-Wave certified controller. HS-FC200+ supports the latest S2 security offered by Z-Wave certified controllers. If your controller supports S2, please refer to the user guide of the controller for detailed instructions on removing devices from the network. You should be able to remove HS-FC200+ into your network using the unique QR code or the DSK 5 digit pin located on the product or packaging. In addition, the device can be added or removed using the following 2-step procedure:1. Put your Z-Wave controller into Exclusion mode. Consult your controller manual if you're unsure how to do this.2. Tap the paddle of your new HomeSeer switch to begin the Exclusion process. This will take a few moments to complete.

Quick trouble shooting

Here are a few hints for network installation if things dont work as expected.

  1. Make sure a device is in factory reset state before including. In doubt exclude before include.
  2. If inclusion still fails, check if both devices use the same frequency.
  3. Remove all dead devices from associations. Otherwise you will see severe delays.
  4. Never use sleeping battery devices without a central controller.
  5. Dont poll FLIRS devices.
  6. Make sure to have enough mains powered device to benefit from the meshing

Association - one device controls an other device

Z-Wave devices control other Z-Wave devices. The relationship between one device controlling another device is called association. In order to control a different device, the controlling device needs to maintain a list of devices that will receive controlling commands. These lists are called association groups and they are always related to certain events (e.g. button pressed, sensor triggers, ...). In case the event happens all devices stored in the respective association group will receive the same wireless command wireless command, typically a 'Basic Set' Command.

Association Groups:

Group Number Maximum Nodes Description
1 5 Z-Wave Plus Lifeline

Configuration Parameters

Z-Wave products are supposed to work out of the box after inclusion, however certain configuration can adapt the function better to user needs or unlock further enhanced features.

IMPORTANT: Controllers may only allow configuring signed values. In order to set values in the range 128 ... 255 the value sent in the application shall be the desired value minus 256. For example: To set a parameter to 200 it may be needed to set a value of 200 minus 256 = minus 56. In case of a two byte value the same logic applies: Values greater than 32768 may needed to be given as negative values too.

Parameter 13: Sets LED indicator mode of operation

0=Fan Controller LED acts like a Fan Controller1=Fan Controller LED acts like a status indicator (LEDs should display the current fan speed level when you tap the paddle)
Size: 1 Byte, Default Value: 0

Setting Description
0 - 1 0=Fan Controller LED acts like a Fan Controller 1=Fan Controller LED acts like a status indicator (LEDs should display the current fan speed level when you tap the paddle)

Parameter 14: Sets the Normal mode LED color

Sets the default LED color when the Fan Controller is NOT in status mode. All LEDS will use this color in this mode. The color values are:0=White1=Red2=Green3=Blue4=Magenta5=Yellow6=Cyan
Size: 1 Byte, Default Value: 0

Setting Description
0 - 6 Sets the default LED color when the Fan Controller is NOT in status mode. All LEDS will use this color in this mode. The color values are:0=White 1=Red 2=Green 3=Blue 4=Magenta 5=Yellow 6=Cyan

Parameter 21: Sets status mode LED 1 bottom color

Sets status mode LED 1 bottom color0=Off1=Red2=Green3=Blue4=Magenta5=Yellow6=Cyan7=White
Size: 1 Byte, Default Value: 0

Setting Description
0 - 7 Sets status mode LED 1 bottom color0=Off 1=Red 2=Green 3=Blue 4=Magenta 5=Yellow 6=Cyan 7=White

Parameter 22: Sets status mode LED 2 color

Sets status mode LED 2 color0=Off1=Red2=Green3=Blue4=Magenta5=Yellow6=Cyan7=White
Size: 1 Byte, Default Value: 0

Setting Description
0 - 7 Sets status mode LED 2 color0=Off 1=Red 2=Green 3=Blue 4=Magenta 5=Yellow 6=Cyan 7=White

Parameter 23: Sets status mode LED 3 color

Sets status mode LED 3 color0=Off1=Red2=Green3=Blue4=Magenta5=Yellow6=Cyan7=White
Size: 1 Byte, Default Value: 0

Setting Description
0 - 7 Sets status mode LED 3 color0=Off 1=Red 2=Green 3=Blue 4=Magenta 5=Yellow 6=Cyan 7=White

Parameter 24: Sets status mode LED 4 color

Sets status mode LED 4 color0=Off1=Red2=Green3=Blue4=Magenta5=Yellow6=Cyan7=White
Size: 1 Byte, Default Value: 0

Setting Description
0 - 7 Sets status mode LED 4 color0=Off 1=Red 2=Green 3=Blue 4=Magenta 5=Yellow 6=Cyan 7=White

Parameter 3: Nightlight Mode

Nightlight Mode, sets bottom LED operation (in normal mode).0= bottom LED on if load is off.1= off if load is off
Size: 1 Byte, Default Value: 1

Setting Description
0 - 1 0= bottom LED on if load is off. 1= off if load is off

Parameter 30: Sets the Blink frequency for All LEDs in Status mode

Sets the Blink frequency for All LEDs in Status modePossible values: 0-2550= No blink, 1=100ms (100 ms off then 100ms on)
Size: 1 Byte, Default Value: 0

Setting Description
0 - 255 0= No blink, 1=100ms (100 ms off then 100ms on)

Parameter 31: Sets LEDs 1-4 to Blink in Status mode

Bitmask defines specific LEDs to enable for blinking.Note: this decimal value is derived from a hex code calculation based on the following:0x01 = led 10x02 = led 20x04 = led 30x08 = led 40 = All LED's disabled1 = LED 12 = LED 23 = LED 1 and 24 = LED 35 = LED 3 and 16 = LED 3 and 27 = LED 3 and 2 and 18 = LED 49 = LED 4 and 110 = LED 4 and 211 = LED 4 and 2 and 112 = LED 4 and 313 = LED 4 and 3 and 114 = LED 4 and 3 and 215 = LED 4 and 3 and 2 and 1
Size: 1 Byte, Default Value: 0

Setting Description
0 - 15 0 = All LEDs disabled 1 = LED 1 2 = LED 2 3 = LED 1 and 2 4 = LED 3 5 = LED 3 and 1 6 = LED 3 and 2 7 = LED 3 and 2 and 1 8 = LED 4 9 = LED 4 and 1 10 = LED 4 and 2 11 = LED 4 and 2 and 1 12 = LED 4 and 3 13 = LED 4 and 3 and 1 14 = LED 4 and 3 and 2 15 = LED 4 and 3 and 2 and 1

Parameter 4: Sets paddles load orientation

Sets whether the top or the bottom paddle turns the load ON
Size: 1 Byte, Default Value: 0

Setting Description
0 - 1 0 = Top On 1 = Bottom On

Parameter 5: Sets fan type

Sets the supported fan type, 3 or 4 speed
Size: 1 Byte, Default Value: 0

Setting Description
0 - 1 0=3 speed fan 1=4 speed fan

Technical Data

Hardware Platform ZM5101
Device Type Fan Switch
Network Operation Always On Slave
Firmware Version HW: 255 FW: 50.01
Z-Wave Version 6.81.00
Certification ID ZC10-18066137
Z-Wave Product Id 0x000C.0x0203.0x0001
Outdoor Use ok
Electric Load Type Inductive (e.g. Motor)
Z-Wave Scene Type Scene & Central Scene
Switch Type Decorator Paddle Rocker
Neutral Wire Required ok
Firmware Updatable Updatable by Consumer by RF
Color White
Security V2 S2_UNAUTHENTICATED ,S2_AUTHENTICATED
Frequency XXfrequency
Maximum transmission power XXantenna

Supported Command Classes

  • Association Grp Info
  • Association V2
  • Basic
  • Central Scene V3
  • Configuration V3
  • Device Reset Locally
  • Firmware Update Md V4
  • Manufacturer Specific V2
  • Powerlevel
  • Scene Activation
  • Scene Actuator Conf
  • Security 2
  • Supervision
  • Switch Multilevel V4
  • Transport Service V2
  • Version V3
  • Zwaveplus Info V2
    •

Controlled Command Classes

  • Central Scene V3
  • Supervision
    •

Explanation of Z-Wave specific terms

  • Controller — is a Z-Wave device with capabilities to manage the network. Controllers are typically Gateways,Remote Controls or battery operated wall controllers.
  • Slave — is a Z-Wave device without capabilities to manage the network. Slaves can be sensors, actuators and even remote controls.
  • Primary Controller — is the central organizer of the network. It must be a controller. There can be only one primary controller in a Z-Wave network.
  • Inclusion — is the process of adding new Z-Wave devices into a network.
  • Exclusion — is the process of removing Z-Wave devices from the network.
  • Association — is a control relationship between a controlling device and a controlled device.
  • Wakeup Notification — is a special wireless message issued by a Z-Wave device to announces that is able to communicate.
  • Node Information Frame — is a special wireless message issued by a Z-Wave device to announce its capabilities and functions.
